TeraStation™ 1000 Series Rackmount

Buffalo’s TeraStation 1000 Rackmount Series is a budget friendly four-drive network storage solution ideal for entry-level backup rackmunt storage requiring a reliable RAID-based network storage, providing dependable performance during file transfers and everyday NAS functions.



This product is currently while supplies last. The TeraStation 3010 Rackmount & Desktop devices are the direct replacement.

Click here for Desktop Lineup


Click to check price Click to contact sales



Overview

Buffalo's Data Recovery Service

Highlights

  • Pre-tested Hard drives included with RAID pre-configured
  • NAS solution / Hot Swap Hard Drive feature with $100 value rackmount rail kit included
  • Private Cloud / DLNA Certified
  • Personal Cloud for access to your files anywhere with internet access
  • Business-level sever/PC backup NovaBACKUP® software bundled
  • Optimized performance for SOHO 1 - 10 concurrent users
  • 3 years Standard Warranty

Easy and Simple: Save your time and money with all inclusive backup

With hard drives and rail kit included, the TeraStation is a one-stop, all-inclusive backup and recovery storage solution.

We make it easy for you, and this is a key factor in choosing Buffalo NAS.



  • Comes with features to make it easy for you to manage your NAS and its users
  • Pre-tested hard drives included with pre-configured RAID
  • TeraStation data can easily back up to external storage (DriveStation)

Backup and Share Your Data

TeraStation 1000 is affordable entry-level backup target to protect your data.



All Buffalo TeraStations comes with NovaStor NovaBACKUP licenses included.  The best single-server and PC backup software for servers and workstations.



TeraStation also offers the storage solution for increasing needs for easy data management for multiple user file share at a fast speed. With Web Access feature, you can access your data from anywhere

Specifications

Models

Part numbers TS1400R0404
TS1400R0804
TS1400R1204
TS1400R1604
Form factor Rackmount: TeraStation™ 1400R

Performance

Processor 1.2 GHz Dual-Issue ARM
Memory 512 MB DDR3

Internal Hard Drives

Number of drive bays 4: TeraStation™ 1400R
Capacity

4TB: TS1400R0404 (1 x 4TB)
8TB: TS1400R0804 (4 x 2TB)
12TB: TS1400R1204 (4 x 3TB)
16TB: TS14001604 (4 x 4TB)
Drive interface SATA 3 Gbps
Supported RAID levels
0/1/5/6/10/JBOD: TeraStation™ 1400R

LAN Interface

Standards compliance IEEE802.3 (10BASE-T), IEEE802.3u (100BASE-TX), IEEE802.3ab (1000BASE-T), AUTO-MDIX
Data transfer rates 10/100/1000 Mbps (auto sensing)
Number of ports 1
Connector type RJ-45
Supported protocols TCP/IP
Network file services CIFS/SMB, AFP, HTTP/HTTPS, FTP/SFTP, NFS

USB Interface

Standards compliance USB 3.0, USB 2.0: TeraStation™ 1400R
Data transfer rates 5 Gbps* (USB 3.0)
480 Mbps* (USB 2.0)
Number of ports 2 x USB 3.0, 1 x USB 2.0: TeraStation™ 1400R

* 480 Mbps and 5 Gbps are the maximum transfer rates derived from the specifications of the Universal Serial Bus 2.0 and 3.0. Actual transfer rates will vary depending upon environmental factors. Data rates, features and performance may vary based on the configuration of your system and other factors. - See more at: http://buffalo.parscalecloud.com/products/terastation-1000-series#sthash.pWuWK3nD.dpuf

Environmental and Power

Power consumption 150W Max: TeraStation™ 1400R
Power supply External AC 100-240V, Universal 50/60Hz: TeraStation™ 1200D, TeraStation™ 1400D
Internal AC 100-240V, Universal 50/60Hz: TeraStation™ 1400R
Operating temperature 41° - 95°F (5° - 35°C)
Operating humidity 20 - 80% non-condensing

Other

Dimensions (L x W x H) 8.03 x 3.43 x 5 in: TeraStation™ 1200D
8.94 x 6.97 x 5.02 in: TeraStation™ 1400D
16.93 x 16.91 x 1.74 in: TeraStation™ 1400R
Weight 5.29 lbs: TeraStation™ 1200D
11.9 lbs: TeraStation™ 1400D
19.84 lbs: TeraStation™ 1400R
Compatible hard drives (TeraStation™ 1200D & 1400D) OP-HD1.0BST-3Y
OP-HD2.0BST-3Y
OP-HD3.0BST-3Y
OP-HD4.0BST-3Y
Compatible hard drives (TeraStation™ 1400R) OP-HD1.0S-3Y
OP-HD2.0S-3Y
OP-HD3.0S-3Y
OP-HD4.0S-3Y
Client OS support Windows® 10
Windows® 8.1 (32-bit/64-bit)
Windows® 8 (32-bit/64-bit)
Windows® 7 (32-bit/64-bit)
Windows Vista® (32-bit/64-bit)
Windows Server® 2012 R2
Windows Server® 2012
Windows Server® 2008 R2
Windows Server® 2008
Windows Server® 2003
Mac OS® X up to 10.10*

*Some included optional utilities are not supported

Included software TeraNavigator
NASNavigator2
TurboPC EX*
NovaBACKUP®
WebManual
Adobe® Reader®

* Only included with TeraStation™ 1200

Box contents TeraStation™
Utility CD (TeraNavigator, NASNavigator2, NovaBACKUP®, Adobe® Reader®)
Quick setup guide
Ethernet cable
AC adapter
AC cable
Warranty statement
  TS1400R
Part Number

TS1400D0404
TS1400D0804
TS1400D1204
TS1400D1604
Form Factor Rackmount

Resources

Downloads

Firmware

    File Size Post Date Version OS Support Notes
Download 2022-01-24 1.68 Windows TS1000 Firmware updater for Windows. SHA 256 hash - F9EE3C23C1EE9FB1F4780597E6FE7C4448A92BA456B5B991613E367207DF00D8
Download 2022-01-24 1.68 Mac TS1000 Firmware updater for Mac. SHA 256 hash - FB94638E45A70157839763EB5C8A0E759505F99410438B72BA6547A6B84665E6

Documentation

    File Size Post Date Version OS Support Notes
Open Link 2016-04-28 User's Manual and Quick Setup Guides for TS1200 TeraStation
Open Link 2016-04-28 User's Manual and Quick Setup Guides for TS1400D
Open Link 2016-04-28 User's Manual and Quick Setup Guides for TS1400R
Download 2022-01-24 1.68 Windows Readme for TS1000 firmware updater for Windows.
Download 2022-01-24 1.68 Mac Readme for TS1000 firmware updater for Mac.
Download 2026-05-13 3.1.4 Windows Readme for NAS Navigator for Windows
Download 2019-07-18 2.99 Windows Lisez-moi pour NAS Navigator pour Windows (français)
Download 2019-07-18 2.99 Mac Readme for NAS Navigator for Mac NOTE: For users running MacOS 10.13 or later, download and install the latest version of NAS Navigator2 from Mac App Store.
Download 2019-07-18 2.99 Mac Lisez-moi pour NAS Navigator pour Mac (français) REMARQUE: pour les utilisateurs d'ordinateurs sous MacOS 10.13 ou ultérieur, téléchargez et installez la dernière version de NAS Navigator2 à partir du Mac App Store.
Download 2016-04-25 1.01 Windows Readme for TeraNavigator for Windows
Download 2016-04-25 1.10 Mac Readme for TeraNavigator for Mac
Download 1.73 KB 2016-04-25 1.13 Windows Readme for the File-sharing Security Level Changing Tool.

Utilities

    File Size Post Date Version OS Support Notes
Download 2019-07-18 2.99 Mac NAS Navigator for Mac NOTE: For users running MacOS 10.13 or later, download and install the latest version of NAS Navigator2 from Mac App Store. SHA256 Hash: A234CBCBF1B185F8594848A809C629E8A3B67683B86D4A591E2A2E106D38CADA
Serial Number Lookup 2016-05-05 1.01 Windows TeraNavigator for Windows
Serial Number Lookup 2016-05-05 1.10 Mac TeraNavigator for Mac
Download 493.18 KB 2016-04-25 1.13 Windows Tool for Changing the File-sharing Security Level. Before delegating authority to an external SMB server on your LinkStation or TeraStation, use this utility to change the file sharing security level of your Windows Vista, Windows 7, Windows 8, Windows Server 2003, or Windows Server 2008 computer.
Open Link 2019-08-05 Windows How to obtain NovaBackup software

Variations


TS1400R0404

TeraStation™ 1400R 4TB

  • - Rackmount
  • - 4
  • - 4
TS1400R0804

TeraStation™ 1400R 8TB

  • - Rackmount
  • - 4
  • - 8
TS1400R1204

TeraStation™ 1400R 12TB

  • - Rackmount
  • - 4
  • - 12
TS1400R1604

TeraStation™ 1400R 16TB

  • - Rackmount
  • - 4
  • - 16
